Cold Paint Road Marking Machine for Durable Line Striping on Asphalt & Concrete - Trusted Worldwide
Widely Used For Roads & Highways, Parking & Commercial Areas, Airports & Transport Hubs, Public & Private Properties, Special Road Markings
Color Customized White/Yellow/Blue/Other Colors
Free Samples 3-Day Global Shipping （No Hidden Costs)
Standard CE Marking/ISO 9001:2015/EN 1871/EPA/RoHS
MOQ 1 set, Fast Delivery: 7-15 Days
White/Yellow/Blue/Other Colors
We welcome sample requests.
Road marking paint plays a vital role in traffic management, improving safety, efficiency, and organization across different environments. From highways to urban roads, and even specialized areas like transport hubs and industrial zones, high-quality road markings enhance visibility and guide road users effectively.
| Item | Specification |
| Model | CPM-100 / CPM-200 / Customizable |
| Marking Type | Cold solvent-based or water-based paint |
| Marking Width | 50 – 450 mm (adjustable) |
| Line Thickness | 0.2 – 0.6 mm |
| Paint Tank Capacity | 60L – 150L |
| Bead Tank Capacity | 10L – 50L (optional) |
| Marking Gun | Single or double spray gun, manual or automatic |
| Spray Method | Airless spraying / High-pressure spraying |
| Pump Type | Plunger pump / Diaphragm pump |
| Drive Method | Manual push / Self-propelled / Truck mounted |
| Engine Type | Gasoline engine (Honda/Rato) or electric motor |
| Power Output | 4.8 HP – 6.5 HP |
| Operation Speed | Up to 10 km/h (self-propelled type) |
| Control System | Manual switch / Electric start / Digital controller (optional) |
| Cleaning System | Built-in solvent tank or manual cleaning |
| Application Scope | Urban roads, parking lots, schools, warehouses |
| Machine Weight | 80 – 160 kg (depending on model) |
| Dimensions (L×W×H) | 1100×900×1050 mm approx. |
| Optional Functions | Night lighting system, laser guide, double-line spraying, logo printing |
It supports both water-based and solvent-based cold paints designed for airless spray systems.
Yes, it performs well on a variety of surfaces including asphalt, concrete, and sealed pavements.
Spray width is adjustable, typically ranging from 5 cm to 30 cm depending on the nozzle setup.
Yes, it comes with a high-capacity paint tank and can be paired with ride-on systems for highways and airports.
Simply flush with water or solvent (depending on the paint type) through the pump and spray gun.
Superior Reflective Performance
Optimized Safety Solutions
Engineered Industrial Durability
Rapid Application Technology
Eco-Friendly Aesthetic Appeal
Vibrant, Long-Lasting Markings
Robust Corrosion Protection
High Visibility Assurance
This cold paint marking machine performed excellently in Malaysia. Lightweight, easy to maneuver, and sprays clean lines. Great for city maintenance crews like ours.
In Senegal, we used this for inner-city roads. Good pressure control and very low paint waste. A solid machine for budget-conscious road departments.
This machine worked well on Ecuador’s mountain roads. Consistent line width, easy to clean, and durable. Perfect for smaller municipalities with limited staff.
We used this in Oman under extreme heat. The cold paint system performed well. Portable and reliable. Ideal for narrow streets and maintenance zones.
This road marking machine made our work in Kyrgyzstan much easier. It’s fuel-efficient and the line quality is excellent. Great for regional contractors.
Kenya’s coastal weather is challenging, but this cold paint machine handled it well. Smooth application, easy to push, and fast drying time. Highly recommended.
