Thermoplastic road marking machine for highway and city streets - Trusted Worldwide
Widely Used For Roads & Highways, Parking & Commercial Areas, Airports & Transport Hubs, Public & Private Properties, Special Road Markings
Color Customized White/Yellow/Blue/Other Colors
Free Samples 3-Day Global Shipping （No Hidden Costs)
Standard CE Certification/ISO 9001/SGS Paint Safety Verification/RoHS/EN 1436
MOQ 1 set, Fast Delivery: 7-15 Days
White/Yellow/Blue/Other Colors
We welcome sample requests.
Road marking paint plays a vital role in traffic management, improving safety, efficiency, and organization across different environments. From highways to urban roads, and even specialized areas like transport hubs and industrial zones, high-quality road markings enhance visibility and guide road users effectively.
| Product Name | Thermoplastic Road Marking Machine |
| Model Options | Hand-Push (e.g., RS-1, ST-150), Self-Propelled (e.g., ALT TC 500S, DP-3800L), Driving Type (e.g., ST-300) |
| Marking Width | 50 mm to 500 mm (customizable) |
| Marking Thickness | 1 mm to 4 mm (adjustable) |
| Marking Speed | Up to 1,200 meters per hour |
| Paint Tank Capacity | 100 kg, 200 kg, 300 kg, 400 kg, 600 kg, or customized |
| Glass Beads Tank Capacity | 10 kg, 12 kg, 55 kg, 150 kg, 160 kg, or customized |
| Fuel Tank Capacity | 15 kg, 40 L, 60 L, 100 L, 200 L, or customized |
| Engine | Gasoline or diesel engines ranging from 6.0 hp to 98.0 hp (depending on model) |
| Compressor Capacity | 0.6 m³/min to 3.8 m³/min (depending on model) |
| Heating Method | Liquefied Petroleum Gas (LPG) heating, diesel heating, infrared heating, or thermal oil heating |
| Operating Temperature | 180°C to 220°C |
| Machine Weight | Approximately 125 kg to 5,620 kg (depending on model and configuration) |
| Machine Dimensions (L×W×H) | From 1,210 mm × 760 mm × 950 mm to 6,000 mm × 2,300 mm × 2,850 mm (depending on model) |
| Operation Type | Hand-Push, Self-Propelled, or Driving Type |
| Glass Bead Dispenser | Automatic or adjustable dispensers synchronized with marking speed |
| Line Types | Solid lines, dashed lines, arrows, letters, convex lines, and more |
| Control System | Digital intelligent control systems with touch screens and multiple language options |
| Optional Features | Double dispensers, adjustable dispensers, double-line die shoes, pre-marking systems, trailers, laser guide pointers, LED signalization, and more |
| Standard Features | High-temperature-resistant tires, stainless steel paint mixing drums, and imported scraper materials for precise line marking |
| Storage Conditions | Store in a dry, ventilated, and cool place, away from direct sunlight |
| Warranty | Typically 12 months, subject to manufacturer terms |
| Certifications | CE, ISO 9001, SGS, and other relevant certifications |
It uses hot-melt thermoplastic road marking paint, applied at 160–220°C.
Thermoplastic paint usually dries in under 5 minutes, depending on weather and surface.
Yes, line width is adjustable between 10–45 cm with interchangeable marking shoes.
Yes, it includes a gravity or pressurized glass bead dispenser for retroreflectivity.
Absolutely. It performs reliably in environments from -10°C to 50°C, including humid and arid conditions.
Superior Reflective Performance
Optimized Safety Solutions
Engineered Industrial Durability
Rapid Application Technology
Eco-Friendly Aesthetic Appeal
Vibrant, Long-Lasting Markings
Robust Corrosion Protection
High Visibility Assurance
This thermoplastic marking machine worked great in Iran. Strong heating system, sharp lines, and easy to handle. It’s built for long hours on highways.
In Chile, we used this for multiple urban roads. Clean melting, precise markings, and durable output. It’s ideal for municipal contracts and private projects.
This machine performed well under Somalia's dusty conditions. High-efficiency burner and smooth wheel control. Reliable and safe for narrow roads and terminals.
We used this machine across several Vietnamese roads. Heats evenly, flows smoothly, and produces highly visible lines. Easy training for new workers too.
In Kyrgyzstan, this thermoplastic unit helped us cut marking time by half. Great build quality and steady line thickness. Perfect for government tenders.
In Kenya, we used this on urban and rural roads. Durable performance, consistent temperature, and excellent marking clarity. It’s truly a professional-grade machine.
